Martin Logan Abyss 10

Frequency Response
22–120 Hz ±3 dB (Anechoic via LFE input)

Low Frequency Transducer
Triple 10” (25.4cm) Hybrid Woofer System consisting of a single high-excursion, anodizedaluminum cone in a stamped steel basket with dual anodizedaluminum cone passive radiators

Amplifier
Magnitude MT-1.6kW Amplifier with 1,600W peak (800W continuous)

Digital Signal Processing
Ultra High-Resolution 500MHz Vojtko DSP Engine with 64bit processing

Cabinet
Precision-crafted, sealed MDF enclosure featuring a robust 1-inch thick MDF structure with reinforced baffle

Inputs
Line Level: Left, Right, and LFE
XLR: LFE
Speaker Level: Left and Right (requires banana plugs)

Wireless Input
Integrated Wireless Receiver, Wireless Transmitter Included

Power Draw
Max: 800W
Standby (Wireless Disabled): 0.5W
Standby (Wireless Enabled): <2W
*Transmitter and Subwoofer combined

Feet
Integrated Anti-Vibration Feet (carpet spikes included)

Weight
25.2 kg

Dimensions (HxWxD)*
39.1cm x 38cm x 38cm

Finish
Gloss Black
